Ultra high transparency
Easy to install
Lightweight (single template weighs only 1.4KG) reduces labor and transportation operating costs
| HOLOGRAPHIC LED SCREEN PARAMETER | ||||
| No. | Items | P4-4 | P6-6 | P10-10 |
| 1 | Pixel Pitch | L(4mm)W(4mm) | L(6.25mm)W(6.25mm) | L(10mm)W(10mm) |
| 2 | Display thickness | 1-3mm | ||
| 3 | LED Configuration | SMD2121 RGB 3IN1 | ||
| 4 | LED Panel Size | 1200mm*256mm/Customized | 1200mm*325mm/Customized | 1200mm*250mm/Customized |
| 5 | Pixel Density | 62,500 dots/m² | 25,600 dots/m² | 10,000 dots/m² |
| 6 | Power Consumption (single module) | 4000cd/electricity：1.3A Power: 286W 5000cd/electricity : 1.7A Power: 374W | 4000cd/electricity：1.5A Power: 330W 5000cd/electricity : 1.8A Power: 396W | 4000cd/electricity：1.7A Power: 374W 5000cd/electricity : 1.8A Power: 396W |
| 7 | Screen Weight (single module) | 1.37KG | 1.36KG | 1.35KG |
| 8 | Transparency | ≥70％ | ≥80％ | ≥90％ |
| 9 | IP Rate | IP30 | IP30 | IP30 |
| 10 | MTBF | >10,000 hrs | >10,000 hrs | >10,000 hrs |
| 11 | Brightness | 1200~5500cd/㎡ adjustable | 1200~5500cd/㎡ adjustable | 1200~5500cd/㎡ adjustable |
| 12 | View Angle | H 160°，W 140° | H 160°，W 140° | H 160°，W 140° |
| 13 | Best View Distance | ≥3-150m | ≥5-160m | ≥8-170m |
| 14 | Gray Scale | ≥16bit | ≥16bit | ≥16bit |
| 15 | Refresh Rate | ＞3840HZ | ＞3840HZ | ＞3840HZ |
| 16 | Frame changing frequency | 60fps | 60fps | 60fps |
| 17 | Input voltage | AC 86-264V/60Hz | AC 86-264V/60Hz | AC 86-264V/60Hz |
| 18 | Service life | ≥100,000 hrs | ≥100,000 hrs | ≥100,000 hrs |
| 19 | Temperature | Working:﹣10℃～+65℃ or Storage:﹣40℃～+85℃ | ||
| 20 | Humidity | 10%-90%RH | ||
| 21 | Control System | Colorlight/NovaStar Synchronous/Async | ||
| 22 | Installation | Film on Glass, Hanging, Fixed Mounting, supports cutting and bending to any size. | ||
